Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5E requirements.

Meet TIA/EIA TSB-40

Meet ISO/IEC Generic Cabling Standard 11801

Meet CENELEC Generic Cabling Standard EN50173

Angle: 180 Degree

Termination: 110, KRONE,DUALTypes (3 types)

Electrical:

According to UL 1863

Current rating: 1.5 Amp Max.

Voltage rating: 150 Volts

Contact resistance: 20 m-ohm

Insulation Resistance: 500M-ohm

Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min

Materials:

Housing: PC UL94V-0

IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.

PCB: FR4 1.6mm(0.04") thickness, 2 layers

Contact: PC Ul94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 u" to 50 u" Gold plating on contact area.

RJ45 ethernet cable cat5e cat6 patch panel

1. 19'' fiber patch panel

2.Height: 1U-3U ,Capacity: 12-48

3.Depth:300mm Width: 465mm

12port 24port 48port patch panel descriptions:

1. Top quality steel with cover by electrostatic painted, ensures the strong body and pleasing appearance;

2. For standard 19" racks use (other rack width options available on request);

3. Height: depends on capacity, one Integrated Splice & Distribution

4. Fully stable patch panel, no risk of movement;

5. Protected patch panel offers secure environment for adapters, patch cords and pigtails;

RJ45 cat5e cat 6 12port 24port 48port patch panel
